Gas Liquefaction Plant 750 Nm³/h YPN-750 Liquefaction Nitrogen Equipment ,LIN, Liquid Nitrogen Generator

Specifications:

The followings are the standard products for the Liquefaction Nitrogen Equipment YPN series which are manufactured by our company. Regarding other particular product can be calculated and designed according to the actual requirements.

Typical Product:750 Nm³/h YPN-750 Liquefaction Nitrogen Equipment

Output, purity and pressure

Description:

The nitrogen provided by air separation plant mixing with the expanded and re-warmed circulating nitrogen of liquefaction plant enters to the circulating nitrogen compressor to be compressed, and then goes into the boosting end of expander to raise the pressure, and after being cooled in the water cooler, it goes into the hot end of main heat exchanger in the liquefier cold box again. Most nitrogen is extracted from the heat exchanger to turbo expander for expansion refrigeration, and the expanded low pressure nitrogen with the nitrogen from the hot end of LIN subcooler enters inot the main heat exchanger from the cold end to cool the drag flow nitrogen, and it follows the next circulation at the inlet of circulating nitrogen after re-warmed. The rest nitrogen is continuously cooled, liquefied and subcooled in the main heat exchanger, and after going out of the cold end of main heat exchanger, it enters into LIN subcooler to be subcooled by the throttled liquid nitrogen, and then the product subcooling liquid nitrogen is obtained.

Applications:

1. Nitrogen Services

2. ISO Container Tank Rental

3. Animal husbandry

4. Depth refrigerant

5. Aerospace Science And Technology

6. Pharmaceutical and biotechnology

7. Food and beverage

Competitive Advantage:

1. The on-site operational experience and user’s comments are unceasingly adopted to continuously improve the safety and reliability of air separation plants so that the major accident arising from minor negligence and misoperation can be prevented.

2. Our company is the biggest air separation plant design and manufacture base

3. Perfect technology R&D system

4. High reliability.

5. No gas loss and high yield

6. Low power consumption

7. Low Working Pressure

       Hangyang Cryogenic Liquefaction Equipment Co., Ltd. is one of the holding subsidiaries of Hangyang Co.,Ltd.(stock code:002430), it is organized on the basis of the original Small Scale of ASU Company of Hangzhou Hangyang Co,.Ltd. It is the major engineering, research and manufacturing base for small size of ASU and liquefaction plants in China, It is located in Hangyang Manufacturing Base in Lin'an Economic Development Zone, the address of sales office is No. 592, Zhongshan North Road, Hangzhou. It undertakes engineering consulting, design and manufacture, assembled construction design, installation and commissioning and supply of parts for medium and small size of ASU with its professional quality. It is the main base of design, research and manufacture for the domestic medium and small size of oxygen/nitrogen generating plants, liquid oxygen/liquid nitrogen plants, oxygen/nitrogen liquefiers, high-purity nitrogen generators, vacuum pipes and Pressure Swing Adsorption (PSA) for oxygen/nitrogen generating, etc.; Meanwhile, it is also the professional manufacturer for integrated assembly or skid type of medium size of ASU for leaving workshop by Hangyang, its abilities of design and manufacture for integrated assembly of medium size of ASU reach the leading domestic level. Our company has the independent import and export trade qualification.

      Our company possesses professional technical personnel teams of design and EPC engineering of ASU and also possesses design ability of product such as independent process calculation, project design, unit design, project EPC. The manufacture base of our company was relocated to new site in 2009. Recently, the floor area is 40.34 acres. Combinating with relocation, the imported and set-up professional manufacture production tools, moulds and equipment forms the manufacture ability for manufacture ASU whose capacity is below 30,000Nm3/h. Our company carries out the international administration concept and obtains authentication certificates of management system such as ISO9001, ISO14001 and OHSAS18001 of DET NORSKE VERITAS. Meanwhile, we obtains manufacturing license for pressure vessels manufacture D1 and D2, Zhejiang new high-tech enterprise certificate and small and medium-sized technology-based enterprise certificate, our company possesses impeccably professional manufacturing credentials for medium and small size of ASU.

     Our company sets product research, manufacture, marketing and service in one to elaborately provide general customers superiorly coordinated service on the basis of decades experience in design and manufacture and administration concept by Hangyang. Products involve aspects such as metallurgy, petrifaction, electron, machinery, building materials and aerospace. Our products are not only sold well throughout China, but also sold to the West, and our company becomes the designated supplier for several well-known gases investment companies abroad. In the cooperation with transnational large gases companies, our company absorbs and imports the advanced design concept, strict administration program, exquisite manufacturing technology so as to lead our company to develop in the direction of diversification, exquisite products and large-scale. Hangzhou Hangyang Cryogenic Liquefaction Engineering Co., Ltd. undertakes EPC works of ASU under our company.
